Interactive StakeWise Ethereum staking guide for Ubuntu OS

Integration

StakeWise documentation: https://docs.stakewise.io/

1. Installing StakeWise client

   1. Find the latest stable version of StakeWise client on Github

      • Find latest StakeWise version at https://github.com/stakewise/v3-operator/releases
      • Write latest stable StakeWise version:


        This will update the url links in the guide below.

   2. Download the binary file for your node

      cd ~/downloads && curl -LO https://github.com/stakewise/v3-operator/releases/download/v3.1.10/operator-v3.1.10-linux-amd64.tar.gz

   3. Unpack the client and remove its packed file

      tar xvf operator-v3.1.10-linux-amd64.tar.gz && rm operator-v3.1.10-linux-amd64.tar.gz

   4. Move the client to /usr/local/bin

      sudo cp ~/downloads/operator-v3.1.10-linux-amd64/operator /usr/local/bin/stakewise-operator

   5. Remove downloaded files

      rm -r ~/downloads/operator-v3.1.10-linux-amd64

Add Stakewise operator

StakeWise Operator is a middleware that connects staked ETH in selected StakeWise Vault with actual validator keys connected to the same Vault. StakeWise operator doesn’t replace a validator client and as so, there's still required to to run standard validator client with the validator keystores simultaneously to perform validator duties.

StakeWise documentation: https://docs.stakewise.io/

1. Creating a StakeWise Vault

   You must have a deployed Vault. You can create a new Vault or use an existing one.

   • At https://app.stakewise.io/operate, connect your wallet and create a new (or select your existing) Vault
   • Process vault setup step by step.

     Click at image for full size
   • Once vault is deployed go to its page.

   You will need the vault address. Vault address can be found either in the URL bar or in the "Contract address" field in "Details" section at the bottom of the page. This Vault contract address will be used as the withdrawal address for validator keystores.

   StakeWise Vault address: (lowercased)

2. Prepare validators keystores, deposit data file and wallet for StakeWise eth-stakewise-operator service

   In order to run Operator Service, you must create keystores and deposit data file for your Vault's validators, and set up a hot wallet for Operator Service to handle validator registrations.

   Operator Service has in-built functionality to generate all of the above. If needed, you can check also original guide at https://docs.stakewise.io/for-operators/operator-service.

   • Preparation for offline generation

     For security reasons, it is recommended to perform configuration and generation strictly offline.

     • Download latest StakeWise Operator client
       • On an online machine, download the latest stable version of StakeWise Operator client from StakeWise github page https://github.com/stakewise/v3-operator/releases. Choose a version of the client for operating system you use on the offline machine.
       • Unwrap the downloaded client and move it using USB stick to your offline machine.

   • Offline generation

     On offline PC, unsing the StakeWise operator client, process the operations below:

     • Generate a config.json file

       ./stakewise-operator init --data-dir ./

       Example process & output

       Enter the network name (mainnet, holesky) [mainnet]:
       Enter your vault address: 0xXXXX...
       Choose your mnemonic language (chinese_simplified, chinese_traditional, czech, english, italian, korean, portuguese, spanish) [english]:
       This is your seed phrase. Write it down and store it safely, it is the ONLY way to recover your validator keys.

       pumpkin anxiety private salon inquiry ....


       Press any key when you have written down your mnemonic.

       Please type your mnemonic (separated by spaces) to confirm you have written it down

       : pumpkin anxiety private salon inquiry ....

       done.
       Successfully initialized configuration for vault 0xXXXX...

       The Output is config.json file that keeps mnemonic_next_index value that is used for generating next keystores above the same seed.

     • Generate validator keys

       ./stakewise-operator create-keys --data-dir ./

       Example process & output

       Enter the vault address: 0xXXXX...
       Enter the number of the validator keys to generate: 10
       Enter the mnemonic for generating the validator keys: pumpkin anxiety private salon inquiry ....
       Creating validator keys:    [####################################]  10/10
       Generating deposit data JSON    [####################################]  10/10
       Exporting validator keystores    [####################################]  10/10

       Done. Generated 10 keys for 0xXXXX... vault.
       Keystores saved to ./0xXXXX.../keystores file
       Deposit data saved to ./0xXXXX.../keystores/deposit_data.json file

       Encryption password for keys generation was generated and used automatically and can be found at ./0xXXXX.../keystores/password.txt file.

     • Create Hot wallet

       Run the create-wallet command below to create hot wallet using your mnemonic (note, this mnemonic can be the same as the one used to generate the validator keys, or a new mnemonic if you desire).

       ./stakewise-operator create-wallet --data-dir ./

       Example process & output

       Enter the vault address: 0xXXXX...
       Enter the mnemonic for generating the wallet: pumpkin anxiety private salon inquiry ...
       Done. The wallet and password saved to ./0xXXXX.../wallet directory. The wallet address is: 0x239B...e3Cc

       Within a ./0xXXXX.../wallet directory, there are 2 files now: wallet.json and password.txt.

       Note, you must send some ETH to the wallet for gas expenses. You must keep an eye on your wallet balance, otherwise validators will stop registering if the balance falls too low.

   • Moving StakeWise configuration to staking node

     • Removing password.txt files for security reason

       For security reason, you can write content of following password files on the paper and then remove the passwords from the file.
       • keystores/password.txt
       • wallet/password.txt
     • Copy 0xXXXX... directory from offline PC to your USB stick
     • Copy 0xXXXX... directory from your USB stick to staking node. You can use scp protocol for remote transfer

   Use your preferred methods of generating keystores and deposit data file, such as via Wagyu Keygen, and your preferred tool for generating the hot wallet, such as MetaMask.

   • On offline PC, generate deposit keys with the Vault withdrawal's address. See a keystore guide.
   • Create Hot wallet...

3. Create a StakeWise operator service

   Create a node operator system service for running StakeWise validators and register keystores into it.

   • StakeWise instance (node operator) service name:

   • Create a service user for StakeWise Operator

     sudo useradd --system --no-create-home --shell /bin/false eth-stakewise-operator

   • Create a directory for StakeWise operation configuration data

     sudo mkdir -p /srv/stakewise/ethereum

     • Copy your offline-generated 0xXXXX... folder to this directory to make the Vault data files available at /srv/stakewise/ethereum/0xXXXX...
     • Do not forget to add correct passwords to the passowrd.txt files, if you removed them for the transfer
       • sudo nano /srv/stakewise/ethereum/0xXXXX.../keystores/password.txt
       • sudo nano /srv/stakewise/ethereum/0xXXXX.../wallet/password.txt
     • Set directory ownership

       sudo chown -R eth-stakewise-operator:eth-stakewise-operator /srv/stakewise/ethereum/0xXXXX...

     • Set Read only by owner permission at the password files
       • sudo chmod 400 /srv/stakewise/ethereum/0xXXXX.../keystores/password.txt
       • sudo chmod 400 /srv/stakewise/ethereum/0xXXXX.../wallet/password.txt

   • Create a directory for StakeWise operation database

     sudo mkdir -p /var/lib/ethereum/stakewise/0xXXXX...

     Set directory ownership

     sudo chown -R eth-stakewise-operator:eth-stakewise-operator /var/lib/ethereum/stakewise/0xXXXX...

   • Configurate the eth-stakewise-operator service

     sudo nano /etc/systemd/system/eth-stakewise-operator.service

     Config file is in preparation

     Reload deamon

     sudo systemctl daemon-reload

4. Start the node operator service

   sudo systemctl start eth-stakewise-operator && systemctl status eth-stakewise-operator

   Check the service

   systemctl status eth-stakewise-operator

   Monitor the service

   journalctl -f -u eth-stakewise-operator

   Output:

   2024-07-27 17:20:45 INFO     Starting operator service, version v3.1.10
   INFO     Checking connection to database...
   INFO     Connected to database /var/lib/eth-stakewise/0xXXXX.../operator.db.
   INFO     Checking connection to consensus nodes...
   INFO     Connected to consensus node at http://127.0.0.1:9596. Finalized epoch: 1038841
   INFO     Checking connection to execution nodes...
   INFO     Connected to execution node at http://127.0.0.1:8545. Current block number: 35182233
   INFO     Checking vault address 0xXXXX...
   INFO     Vault withdrawable assets: 0.00 GNO
   INFO     Checking hot wallet balance 0xXXXX... ...
   INFO     Checking connection to ipfs nodes...

   INFO     Connected to ipfs nodes at https://eth-stakewise-v3.infura-ipfs.io, http://cloudflare-ipfs.com, https://gateway.pinata.cloud, https://ipfs.io.
   INFO     Checking connection to oracles set...
   INFO     Connected to oracles at https://gno-stakewise-v3-oracle.pn.prod.fcstech.de, https://gnosis-oracle.stakewise.io, https://stakewise-oracle-gnosis.chorus.one, https://stakewise-oracle-gno-mainnet-1.gateway.fm, https://sw-oracle-gno.axol.io, https://stakewise-oracle-gc.gnosischain.com, https://gnosis-oracle.stakewise.dsrvlabs.net, https://gnosis-oracle-b.stakewise.io, https://stakewise-oracle-v3-gnosis.bitfly.at, https://stakewise-oracle-gc-2.gnosischain.com, https://stakewise-oracle-gnosis.senseinode.com
   INFO     Checking deposit data file...
   INFO     Found deposit data file /srv/eth-stakewise/0xXXXX.../deposit_data.json
   INFO     Checking keystores dir...
   INFO     Found keystores dir
   INFO     Loading keys from /srv/eth-stakewise/0xXXXX.../keystores...
   INFO     Loaded 8 keys
   INFO     Loaded deposit data file /srv/eth-stakewise/0xXXXX.../deposit_data.json
   INFO     Syncing network validator events...
   INFO     Updating oracles cache...
   INFO     Started operator service


5. Enable auto launch on OS startup

   sudo systemctl enable eth-stakewise-operator

   • Extend Staking manager clients.conf

     Insert eth-stakewise-operator into clients.conf file, section stakewiseOperators, that is used by Staking Manager.

     sudo nano /usr/local/etc/staking/config/clients.conf

   • Activate service to start automatically on OS startup

     • Open Start with delay util

       sudo nano /usr/local/bin/delayed-start.sh

     • Place or uncomment a command to start the Beacon client(s)

       /usr/local/bin/staking.sh start stakewise

     • Verify, that a service `delayed-start.service` exists and is automatically launched on system start.

       sudo systemctl enable delayed-start.service

6. Configurate & Run Validator instance performing validation duties

   1. Do you want to create a new validation instance or extend exisiting instance for more validators?

      • Create a directory for validator instance data

        sudo mkdir -p /var/lib/ethereum/lighthouse/vi1

      • Load keystores to /var/lib/ethereum/lighthouse/vi1

        Directory with Deposit Data keystores:

        sudo /usr/local/bin/lighthouse --network mainnet account validator import --reuse-password --directory $HOME/keystores/ddk_i1 --datadir /var/lib/ethereum/lighthouse/vi1

        • Insert keystores encryption password (the one used during keystores generation) on request
        • If there are keystores with different encryption password, repeat the process for each encryption password

      • Create a service user for the validator instance

        sudo useradd --system --no-create-home --shell /bin/false eth-lighthouse-vi1

      • Set ownership of /var/lib/ethereum/lighthouse/vi1 to validators-i1 user

        sudo chown -R eth-lighthouse-vi1:eth-lighthouse-vi1 /var/lib/ethereum/lighthouse/vi1

      • Create configuration service file for eth-lighthouse-vi1 service

        1. Open the configuration file

           sudo nano /etc/systemd/system/eth-lighthouse-vi1.service

        2. Copy the configuration below into the file.

           • What's fee recipient wallet?
           • What's your execution client?

           [Unit]
           Description=Lighthouse Validator Instance (Mainnet)
           Wants=network-online.target
           After=network-online.target
           [Service]
           User=eth-lighthouse-vi1
           Group=eth-lighthouse-vi1
           Type=simple
           Restart=always
           RestartSec=5
           ExecStart=/usr/local/bin/lighthouse vc \
             --network mainnet \
             --datadir /var/lib/ethereum/lighthouse/vi1 \
             --suggested-fee-recipient 0xXXXXXXXXXXXXXXXX \
             --beacon-nodes http://localhost:5052 \
             --graffiti "Nethermind+Lighthouse"
           [Install]
           WantedBy=multi-user.target

        3. Press CTRL + X then Y then ENTER to save and exit the config file.

      • Stop running validator instance eth-lighthouse-vi1

        sudo systemctl stop eth-lighthouse-vi1

      • Extend /var/lib/ethereum/lighthouse/vi1 for new keystores

        sudo /usr/local/bin/lighthouse --network mainnet account validator import --reuse-password --directory $HOME/keystores/ddk_i1 --datadir /var/lib/ethereum/lighthouse/vi1

        • You will be requested to insert keystores encryption password (the one used during keystores generation)
        • If there are keystores with different encryption password, repeat the process for each encryption password
        • Already existing keystores in the directory will be skipped

   2. Load processed changes to the system

      sudo systemctl daemon-reload

   3. Start the validator instance

      sudo systemctl start eth-lighthouse-vi1

   4. Check the running validator instance

      systemctl status eth-lighthouse-vi1

      journalctl -fu eth-lighthouse-vi1

   5. Activate service to start automatically on system startup

      sudo systemctl enable eth-lighthouse-vi1

      • Open Delayed Start shell

        sudo nano /usr/local/bin/delayed-start.sh

        Configurate service start inside it

        systemctl start eth-lighthouse-vi1.service

      • Be sure, delayed-start.service service controlling delayed-start.sh is enabled for auto start with system startup

        sudo systemctl enable delayed-start.service

      1. Configurate Staking Manager util

         • Open the configuration file

           sudo nano /usr/local/etc/staking/config/clients.conf

           If the file is empty, generate it with command sudo /usr/local/bin/staking.sh init

         • Set link to proper service. It should be as follow:

           validatorServices="eth-lighthouse-vi1"

           If you place more services to the category, separate them with a space, see validatorServices="service1 service2 service3 ..."

      2. Activate service to start automatically on OS startup

         • Open Start with delay util

           sudo nano /usr/local/bin/delayed-start.sh

         • Place or uncomment a command to start the validator client(s)

           /usr/local/bin/staking.sh start validators

         • Verify, that a service `delayed-start.service` exists and is automatically launched on system start.

           sudo systemctl enable delayed-start.service

   Guide to exit validator is available at https://stakers.space/lighthouse/exit-validator.

   1. Do you want to create a new validation instance or extend exisiting instance for more validators?

      • Create a directory for validator instance data

        sudo mkdir -p /var/lib/ethereum/lodestar/vi1

      • Enable accessing /var/lib/ethereum/lodestar/vi1 for server user myserveruser

        sudo chown -R myserveruser:myserveruser /var/lib/ethereum/lodestar/vi1

      • Load keystores to /var/lib/ethereum/lodestar/vi1

        Directory with Deposit Data keystores:

        Move to Lodestar client directory

        cd /usr/local/bin/lodestar

        ./lodestar validator import --network mainnet --importKeystores $HOME/keystores/ddk_i1 --dataDir /var/lib/ethereum/lodestar/vi1

        • Insert keystores encryption password (the one used during keystores generation) on request
        • If there are keystores with different encryption password, repeat the process for each encryption password

      • Create a service user for the validator instance

        sudo useradd --system --no-create-home --shell /bin/false eth-lodestar-vi1

      • Set ownership of /var/lib/ethereum/lodestar/vi1 to lodestar-vi1 user

        sudo chown -R eth-lodestar-vi1:eth-lodestar-vi1 /var/lib/ethereum/lodestar/vi1

      • Enable access to NodeJs for user lodestar-vi1

        User with NodeJs:

        sudo usermod -aG nodejsusr eth-lodestar-vi1

      • Create configuration service file for eth-lodestar-vi1 service

        1. Open the configuration file

           sudo nano /etc/systemd/system/eth-lodestar-vi1.service

        2. Copy the configuration below into the file.

           • Installed NodeJs version on the server:
             This can be get with command node version

           • What's fee recipient wallet?
           • What's your execution client?

           [Unit]
           Description=Lodestar Validator Instance (Ethereum Mainnet)
           Wants=network-online.target
           After=network-online.target
           [Service]
           User=eth-lodestar-vi1
           Group=eth-lodestar-vi1
           Type=simple
           Restart=always
           RestartSec=5
           WorkingDirectory=/usr/local/bin/lodestar
           Environment="PATH=/home/nodejsusr/.nvm/versions/node/v/bin:/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
           ExecStart=/usr/local/bin/lodestar/lodestar validator \
             --network mainnet \
             --dataDir /var/lib/ethereum/lodestar/validators/i1 \
             --suggestedFeeRecipient 0xXXXXXXXXXXXXXXXX \
             # ToDo: Add Beacon API URL
             --force \
             --graffiti "Nethermind+Lodestar"
           [Install]
           WantedBy=multi-user.target

        3. Press CTRL + X then Y then ENTER to save and exit the config file.

      • Adding validator instance to staking services manager

        If you use a staking manager client, add the new instance into it.

      • Stop running validator instance eth-lodestar-vi1

        sudo systemctl stop eth-lodestar-vi1

      • Extend /var/lib/ethereum/lodestar/validators/i1 for new keystores

        ./lodestar validator import --network mainnet --importKeystores $HOME/keystores/ddk_i1 --dataDir /var/lib/ethereum/lodestar/vi1

        • You will be requested to insert keystores encryption password (the one used during keystores generation)
        • If there are keystores with different encryption password, repeat the process for each encryption password
        • Already existing keystores in the directory will be skipped

   2. Load processed changes to the system

      sudo systemctl daemon-reload

   3. Start the validator instance

      sudo systemctl start eth-lodestar-vi1

   4. Check the running validator instance

      systemctl status eth-lodestar-vi1

      journalctl -fu eth-lodestar-vi1

   5. Other configurations

      Activate service to start automatically on OS startup

      sudo systemctl enable eth-lodestar-vi1

      • Open Delayed Start shell

        sudo nano /usr/local/bin/delayed-start.sh

        Configurate service start inside it

        systemctl start eth-lodestar-vi1.service

      • Be sure, delayed-start.service service controlling delayed-start.sh is enabled for auto start with system startup

        sudo systemctl enable delayed-start.service

      • Configurate Lodestar validator Log monitor service

        Log monitor service monitors the service log and process defined action (fixes) in a case of any issue detected.

        1. Check, whether the logmonitor util is installed:

           /usr/local/bin/logmonitor.sh version

           If the util is not installed, install Lodestar validator Log monitor from GitHub.

        2. Check defined Errors list for lodestarvalidator service

           sudo nano /usr/local/etc/lodestarvalidator_tracking_records.txt

           If not available, download it from GitHub. You can also modifiy it, if needed.

        3. Configurate the validator log monitor for service eth-lodestar-vi1, see guide on Github.

      • Activate service to start automatically on OS startup

        Our guide uses a custom util for launching services. It has following benefits:

        • It allows set delay for starting services. It eliminates slashing risk in the following scenario:
          1. A database corruption occures
          2. Lodestar Log monitor detects it, stopping the validator instance and clearing broken database
          3. Very quick power failure happens while the staking node starts immediately automatically
          4. As the database with last attestation is removed now, we need to prevent start of the validator instance to avoid double attestation / block proposal within the same slot.
        • It allows starting services through a shared script

          Starting all services through the Staking Manager util and its command /usr/local/bin/staking.sh start validators prevents a human error when there is forgotten set of sudo systemctl enable ... for any staking-related service.

          Extend Staking manager clients.conf

          Insert eth-lodestar-vi1 into clients.conf file that is used by Staking Manager.

          sudo nano /usr/local/etc/staking/config/clients.conf

        There's a Start with delay util to manage this.

        1. Install Start with delay util from GitHub, if not installed yet.
        2. Open Start with delay util

           sudo nano /usr/local/bin/delayed-start.sh

        3. Place new services (validator isntance and validator instance monitor) into the file

           eth-lodestar-vi1

           eth-lodestar-vi1_logmonitor

        4. Place command to start all validator services, if not attached yet

           /usr/local/bin/staking.sh start validators

        5. Verify, that a service `delayed-start.service` exists and is automatically launched on system start. See GitHub for a guide to do that.

   Guide to exit validator is available at https://stakers.space/lodestar/exit-validator.

   1. Do you want to create a new validation instance or extend exisiting instance for more validators?

      • Create a directory for validator instance data

        sudo mkdir -p /var/lib/ethereum/teku/vi1

      • If exists, remove deposit_data file from keystores folder

        Directory with Deposit Data keystores:
        • Display files in the directory

          cd $HOME/keystores/ddk_i1 && ls -lh

        • If there is deposit_data-XXX....json file, remove it

          sudo rm deposit_data-XXX....json

      • Copy keystores dedicated for instance into /var/lib/ethereum/teku/vi1/keystores folder

        sudo mkdir /var/lib/ethereum/teku/vi1/keystores

        sudo cp -a $HOME/keystores/ddk_i1/* /var/lib/ethereum/teku/vi1/keystores && cd /var/lib/ethereum/teku/vi1/keystores

      • Teku requires a .txt file with encryption password for each .json validator file.

        1. Display all keystores in the directory

           ls -lh

        2. Whats's the first keystore name? .json

           Create a new .txt file for the keystore-m_12381_3600_X_0_0-XXXXXXXXXX.json keystore file

           sudo nano keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt

           Insert an encryption password for the validator key (the one used during keystores generation) into that file.

           Press ctrl + x, then y to save and exit

        3. Set readonly permission for that file

           sudo chmod 400 keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt

        Now, you can either repeate the process for all other keystores in the folder, or use an automated solution to duplicate the created password file (with modified name) for all remaining keystores, see Shell Script to generate password files for Teku.

        With automated process, to generate .txt file with a content of /var/lib/ethereum/teku/vi1/keystores/keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt for all remaining keystores in the /var/lib/ethereum/teku/vi1/keystores/ directory, use command

        sudo /opt/teku-create-validator-psw-files.sh /var/lib/ethereum/teku/vi1/keystores/keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt

      • Create a service user for the validator instance

        sudo useradd --system --no-create-home --shell /bin/false eth-teku-vi1

      • Set ownership of validator instance data directory to validator-instance user

        sudo chown -R eth-teku-vi1:eth-teku-vi1 /var/lib/ethereum/teku/vi1

      • Create configuration service file for eth-teku-vi1 service

        1. Open the configuration file

           sudo nano /etc/systemd/system/eth-teku-vi1.service

        2. Copy the configuration below into the file.
           • What's fee recipient wallet?
           • What's your execution client?

           [Unit]
           Description=Teku Validator Instance (Ethereum Mainnet)
           Wants=network-online.target
           After=network-online.target
           [Service]
           User=eth-teku-vi1
           Group=eth-teku-vi1
           Type=simple
           Restart=always
           RestartSec=5
           Environment="JAVA_OPTS=-Xmx4g"
           Environment="TEKU_OPTS=-XX:-HeapDumpOnOutOfMemoryError"
           ExecStart=/usr/local/bin/teku/bin/teku validator-client \
             --network mainnet \
             --beacon-node-api-endpoint http://127.0.0.1:5051 \
             #--beacon-node-api-endpoint http://127.0.0.1:5051,http://192.10.10.101:5051,http://192.140.110.44:5051 \
             --data-path /var/lib/ethereum/teku/vi1 \
             --validator-keys /var/lib/ethereum/teku/vi1/keystores:/var/lib/ethereum/teku/vi1/keystores \
             --validators-proposer-default-fee-recipient 0xXXXXXXXXXXXXXXXX \
             --validators-graffiti "Nethermind+Teku"
           [Install]
           WantedBy=multi-user.target

      • Stop running validator instance eth-teku-vi1

        sudo systemctl stop eth-teku-vi1

      • If exists, remove deposit_data file from keystores folder

        Directory with Deposit Data keystores:
        • Display files in the directory

          cd $HOME/keystores/ddk_i1 && ls -lh

        • If there is deposit_data-XXX....json file, remove it

          rm deposit_data-XXX....json

      • Copy keystores dedicated for instance into /var/lib/ethereum/teku/vi1/keystores folder

        sudo mkdir /var/lib/ethereum/teku/vi1/keystores

        sudo cp -a $HOME/keystores/ddk_i1/* /var/lib/ethereum/teku/vi1/keystores/keystores  && cd /var/lib/ethereum/teku/vi1/keystores

      • Teku requires a .txt file with encryption password for each .json validator file.

        1. Display all keystores in the directory

           ls -lh

        2. Whats's the first keystore name? .json

           Vreate a new .txt file for the keystore-m_12381_3600_X_0_0-XXXXXXXXXX.json keystore file

           nano keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt

           Insert an encryption password for the validator key (the one used during keystores generation) into that file.

           Press ctrl + x, then y to save and exit

        3. Set readonly permission for that file

           sudo chmod 400 keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt

        Now, you can either repeate the process for all other keystores in the folder, or use an automated solution to duplicate the created password file (with modified name) for all remaining keystores, see Shell Script to generate password files for Teku.

        With automated process, to generate .txt file with a content of /var/lib/ethereum/teku/vi1/keystores/keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt for all remaining keystores in the /var/lib/ethereum/teku-vi1/keystores/ directory, use command

        $HOME/bashscripts/create-teku-pswfiles.sh /var/lib/ethereum/teku/vi1/keystores/keystore-m_12381_3600_X_0_0-XXXXXXXXXX.txt

   2. Load changes made in config files to the system

      sudo systemctl daemon-reload

   3. Start the validator instance

      sudo systemctl start eth-teku-vi1

   4. Check the running validator instance

      systemctl status eth-teku-vi1

      journalctl -fu eth-teku-vi1

   5. Activate service to start automatically

      sudo systemctl enable eth-teku-vi1

      • Open Delayed Start shell

        sudo nano /usr/local/bin/delayed-start.sh

        Attach command to remove lock files (to prevent start the validator in a case of existing lock fiels after a power failure). This must be processed before starting the validator service.

        /opt/remove-teku-validator-lock-files.sh '/var/lib/ethereum/teku/vi1/keystores'

        Configurate service start inside it

        systemctl start eth-teku-vi1.service

      • Be sure, delayed-start.service service controlling delayed-start.sh is enabled for auto start with system startup

        sudo systemctl enable delayed-start.service

      1. Configurate Staking Manager util

         • Open the configuration file

           sudo nano /usr/local/etc/staking/config/clients.conf

           If the file is empty, generate it with command sudo /usr/local/bin/staking.sh init

         • Set link to proper service. It should be as follow:

           validatorServices="eth-teku-vi1"

           If you place more services to the category, separate them with a space, see validatorServices="service1 service2 service3 ..."

      2. Activate service to start automatically on OS startup

         • Open Start with delay util

           sudo nano /usr/local/bin/delayed-start.sh

         • Attach command to remove lock files (to prevent start the validator in a case of existing lock fiels after a power failure). This must be processed before starting the validator service.

           /opt/remove-teku-validator-lock-files.sh '/var/lib/ethereum/teku/vi1/keystores'

         • Place or uncomment a command to start the validator client(s)

           /usr/local/bin/staking.sh start validators

         • Verify, that a service `delayed-start.service` exists and is automatically launched on system start.

           sudo systemctl enable delayed-start.service

   Guide to exit validator is available at https://stakers.space/teku/exit-validator.

   1. Do you want to create a new validation instance or extend exisiting instance for more validators?

      • Create a directory for validator instance data

        sudo mkdir -p /var/lib/ethereum/nimbus/vi1

      • Load keystores to /var/lib/ethereum/nimbus/vi1

        Directory with Deposit Data keystores:

        sudo /usr/local/bin/nimbus-validator import data-dir=/var/lib/ethereum/nimbus/vi1 $HOME/keystores/ddk_i1

        NOTE: If you have used different passwords for each of your validators you will get an error. Run the process multiple times, providing each of the different passwords until they are all imported. Use the accounts list command to verify.

      • Create a service user for the validator instance

        sudo useradd --system --no-create-home --shell /bin/false eth-nimbus-vi1

      • Set ownership of /var/lib/ethereum/nimbus/vi1 to validators-i1 user

        sudo chown -R eth-nimbus-vi1:eth-nimbus-vi1 /var/lib/ethereum/nimbus/vi1

      • Create configuration service file for eth-nimbus-vi1 service

        1. Open the configuration file

           sudo nano /etc/systemd/system/eth-nimbus-vi1.service

        2. Copy the configuration below into the file.

           • What's fee recipient wallet?
           • What's your execution client?

           [Unit]
           Description=Nimbus Validator Instance (Ethereum Mainnet)
           Wants=network-online.target
           After=network-online.target
           [Service]
           User=eth-teku-vi1
           Group=eth-teku-vi1
           Type=simple
           Restart=always
           RestartSec=5
           ExecStart=/usr/local/bin/nimbus/nimbus_validator_client \
             --network=mainnet \
             --data-dir=/var/lib/ethereum/nimbus/vi1 \
             --beacon-node=http://127.0.0.1:5052 \
             --suggested-fee-recipient=0xXXXXXXXXXXXXXXXX \
             --graffiti="Nethermind+Nimbus"
             # --payload-builder=true --payload-builder-url=https://${HOST}:${PORT}/

           [Install]
           WantedBy=multi-user.target

           Notes

           • See more flags at https://nimbus.guide/options.html
        3. Press CTRL + X then Y then ENTER to save and exit the config file.

      • Stop running validator instance eth-nimbus-vi1

        sudo systemctl stop eth-nimbus-vi1

      • Extend /var/lib/ethereum/nimbus/vi1 for new keystores

        sudo /usr/local/bin/nimbus-validator import data-dir=/var/lib/ethereum/nimbus/vi1 $HOME/keystores/ddk_i1

        NOTE: If you have used different passwords for each of your validators you will get an error. Run the process multiple times, providing each of the different passwords until they are all imported. Use the accounts list command to verify.

   2. Load processed changes to the system

      sudo systemctl daemon-reload

   3. Start the validator instance

      sudo systemctl start eth-nimbus-vi1

   4. Check the running validator instance

      systemctl status eth-nimbus-vi1

      journalctl -fu eth-nimbus-vi1

   5. Activate service to start automatically

      sudo systemctl enable eth-nimbus-vi1

      • Open Delayed Start shell

        sudo nano /usr/local/bin/delayed-start.sh

        Configurate service start inside it

        systemctl start eth-nimbus-vi1.service

      • Be sure, delayed-start.service service controlling delayed-start.sh is enabled for auto start with system startup

        sudo systemctl enable delayed-start.service

      1. Configurate Staking Manager util

         • Open the configuration file

           sudo nano /usr/local/etc/staking/config/clients.conf

           If the file is empty, generate it with command sudo /usr/local/bin/staking.sh init

         • Set link to proper service. It should be as follow:

           validatorServices="eth-nimbus-vi1"

           If you place more services to the category, separate them with a space, see validatorServices="service1 service2 service3 ..."

      2. Activate service to start automatically on OS startup

         • Open Start with delay util

           sudo nano /usr/local/bin/delayed-start.sh

         • Place or uncomment a command to start the validator client(s)

           /usr/local/bin/staking.sh start validators

         • Verify, that a service `delayed-start.service` exists and is automatically launched on system start.

           sudo systemctl enable delayed-start.service

   Guide to exit validator is available at https://stakers.space/nimbus/exit-validator.

   1. Do you want to create a new validation instance or extend exisiting instance for more validators?

      • Create a directory for validator instance data

        sudo mkdir -p /var/lib/ethereum/prysm/vi1

      • Load keystores to /var/lib/ethereum/prysm/vi1

        Directory with Deposit Data keystores:

        sudo /usr/local/bin/validator accounts import --mainnet --keys-dir=$HOME/keystores/ddk_i1 --wallet-dir=/var/lib/ethereum/prysm/vi1

        • Accept Terms of Use
        • Set a wallet password. This is different to the validator password you set during keys generation. Prysm will use this to decrypt the validator wallet. Back it up somewhere safe. You will need this later in this section and when configuring the validator.
        • Provide the validator keys password. This is the password you set when you created the keys during keys generation

        NOTE: If you have used different passwords for each of your validators you will get an error. Run the process multiple times, providing each of the different passwords until they are all imported. Use the accounts list command to verify.

      • Create a Wallet Password File

        Create a file to store the wallet password so the Prysm validator service can access the wallet without you having to supply the password.

        sudo nano /var/lib/ethereum/prysm/vi1/password.txt

        Press CTRL + X then Y then ENTER to save and exit the config file.

      • Create a service user for the validator instance

        sudo useradd --system --no-create-home --shell /bin/false eth-prysm-vi1

      • Set ownership of /var/lib/ethereum/prysm/vi1 to validators-i1 user

        sudo chown -R eth-prysm-vi1:eth-prysm-vi1 /var/lib/ethereum/prysm/vi1

      • Create configuration service file for eth-prysm-vi1 service

        1. Open the configuration file

           sudo nano /etc/systemd/system/eth-prysm-vi1.service

        2. Copy the configuration below into the file.

           • What's fee recipient wallet?
           • What's your execution client?

           [Unit]
           Description=Prysm Consensus Client VC (Mainnet)
           Wants=network-online.target
           After=network-online.target

           [Service]
           User=eth-prysm-vi1
           Group=eth-prysm-vi1
           Type=simple
           Restart=always
           RestartSec=5
           ExecStart=/usr/local/bin/validator \
             --datadir=/var/lib/ethereum/prysm/vi1 \
             --wallet-dir=/var/lib/ethereum/prysm/vi1 \
             --wallet-password-file=/var/lib/ethereum/prysm/vi1/password.txt \
             --suggested-fee-recipient=0xXXXXXXXXXXXXXXXX \
             --graffiti="Nethermind+Prysm" \
             --accept-terms-of-use

           [Install]
           WantedBy=multi-user.target

        3. Press CTRL + X then Y then ENTER to save and exit the config file.

      • Stop running validator instance eth-prysm-vi1

        sudo systemctl stop eth-prysm-vi1

      • Extend /var/lib/ethereum/prysm/vi1 for new keystores

        sudo /usr/local/bin/validator accounts import --mainnet --keys-dir=$HOME/keystores/ddk_i1 --wallet-dir=/var/lib/ethereum/prysm/vi1

        • Accept Terms of Use
        • Set a wallet password. This is different to the validator password you set during keys generation. Prysm will use this to decrypt the validator wallet. Back it up somewhere safe. You will need this later in this section and when configuring the validator.
        • Provide the validator keys password. This is the password you set when you created the keys during keys generation

        NOTE: If you have used different passwords for each of your validators you will get an error. Run the process multiple times, providing each of the different passwords until they are all imported. Use the accounts list command to verify.

   2. Load processed changes to the system

      sudo systemctl daemon-reload

   3. Start the validator instance

      sudo systemctl start eth-prysm-vi1

   4. Check the running validator instance

      systemctl status eth-prysm-vi1

      journalctl -fu eth-prysm-vi1

   5. Activate service to start automatically

      sudo systemctl enable eth-prysm-vi1

      • Open Delayed Start shell

        sudo nano /usr/local/bin/delayed-start.sh

        Configurate service start inside it

        systemctl start eth-prysm-vi1.service

      • Be sure, delayed-start.service service controlling delayed-start.sh is enabled for auto start with system startup

        sudo systemctl enable delayed-start.service

      1. Configurate Staking Manager util

         • Open the configuration file

           sudo nano /usr/local/etc/staking/config/clients.conf

           If the file is empty, generate it with command sudo /usr/local/bin/staking.sh init

         • Set link to proper service. It should be as follow:

           validatorServices="eth-prysm-vi1"

           If you place more services to the category, separate them with a space, see validatorServices="service1 service2 service3 ..."

      2. Activate service to start automatically on OS startup

         • Open Start with delay util

           sudo nano /usr/local/bin/delayed-start.sh

         • Place or uncomment a command to start the validator client(s)

           /usr/local/bin/staking.sh start validators

         • Verify, that a service `delayed-start.service` exists and is automatically launched on system start.

           sudo systemctl enable delayed-start.service

   Guide to exit validator is available at https://stakers.space/prysm/exit-validator.

7. Upload deposit file to the 0xXXXX... vault

   Once you have created your validator keys, deposit data file, and hot wallet, you need to upload the deposit data file to the Vault. This process connects your node to the Vault. Note, if there is more than one node operator in a Vault, you first need to merge all operator deposit data files into a single file (use the ./stakewise-operator merge-deposit-data command). Uploading the deposit data file can be achieved either through the StakeWise UI or via Operator Service and can only be done by the Vault Admin or Keys Manager.

   Upload the deposit data file either over the web StakeWise vault web UI or StakeWise operator service

   1. Connect with your wallet to StakeWise Operate webpage
   2. Select the Vault you want to upload the deposit data file to.
   3. In the upper right corner, click on "Settings" and open the "Deposit Data" tab. The "Settings" button is only visible to the Vault Admin or Keys Manager.
   4. Upload the deposit data file either by dragging and dropping the file, or clicking to choose the file via your file browser.
   5. Click Save and a transaction will be created to sign using your wallet. The Vault's deposit data file will be uploaded when the transaction is confirmed on the network.

   You can calculate deposit data Merkle tree root with the following command:

   sudo /usr/local/bin/stakewise-operator get-validators-root --data-dir /srv/eth-stakewise

   Example process & output

   Enter the vault address: 0xXXXX...
   The validator deposit data Merkle tree root: 0x504...26d7

   For other steps, check StakeWise guide, section Upload deposit data file to Vault, tab Operate Service.

8. Extend validators set for other validators

   If there is allocated more ETH in the Vault deposit contract than a number of generated validator keys for the Vault contract, the operator informs about that with following message:

   stakewise-operator: YYYY-MM-DD HH:MM:SS WARNING  There are no available validators in the current deposit data to proceed with registration. To register additional validators, you must upload new deposit data.

   For option to register and launch other validators, you must do following:

   • On Offline PC, generate more validator keys for the Vault
   • On your staking node:
     1. Register the new keystores into a standard validator instance - either extend existing or create a new.
     2. Stop StakeWise Operator
     3. Copy the new validator keys to stakewise operator keystores directory /srv/stakewise/ethereum/0xXXXX.../keystores
     4. Replace the old depost-data.json file at /srv/eth-stakewise/0xXXXX.../deposit_data.json. take into notice, that the deposit_data.json file must contain only keystores that were not deposited yet.
     5. Start StakeWise Operator again
     6. As there is a different deposit_data.json file at your staking operator and on the Vault, you will see following log in the operator:

        ERROR    Deposit data tree root and vault's validators root don't match. Have you updated vault deposit data?

     7. Upload a new deposit_data.json file (same as on the operator) to the Stakevise Vault through Web UI. After that, operator should work properly again and pending ETH should be immediatelly allocated into newly registered validators.
